API
Documentation

Complete reference for integrating with the WAPit WhatsApp messaging gateway. Send text, media, audio, location, templates, and interactive messages. Manage templates, upload media, and control your business profile via a simple REST API.

Get API Credentials

Base URL

All API requests are made to:

https://wowresult-174418289148.europe-west1.run.app

For local development: http://localhost:8080

Authentication

All API endpoints (except /health and /auth/login) require a valid JWT token.

POST/auth/login

Get Authentication Token

Exchange your API credentials for a JWT token. Tokens are valid for 24 hours.

Request

POST /auth/login
Content-Type: application/json

{
  "username": "carleads_api",
  "password": "your_secure_password"
}

Response (200 OK)

{
  "success": true,
  "token": "eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...",
  "expires_in": 86400,
  "expires_at": "2026-07-04T14:30:00Z"
}

Using the Token

Include the token in all subsequent requests:

Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...

Common Request Fields

All send endpoints share these fields. The content object varies per message type.

Field	Type	Required	Description
message_id	string	Yes	Your unique batch/request tracking ID
client_id	string	Yes	Your tenant/client identifier
campaign_id	string	Yes	Campaign slug (must match a campaign in the system)
wa_number_id	string	Yes	Which WA number to send from (e.g. "1" or "2")
callback_url	string	Yes	URL where delivery statuses and replies will be POSTed
recipients	array	Yes	Array of recipient objects (see below)
content	object	Yes	Message content (varies per endpoint)

Recipient Object

Field	Type	Required	Description
recipient_id	string	Yes	Your unique ID for this recipient
phone	string	Yes	Phone number (SA format auto-detected: 082... → 2782...)
name	string	No	Recipient name (replaces {{name}} in message body)

Phone normalization: South African numbers are automatically converted (e.g. 0825551234 → 27825551234). International numbers should include the country code without the + prefix.

Personalization: Use {{name}}in message body/caption fields. It will be replaced with each recipient's name field.

Contact lists: Fetch contacts from GET /api/v1/contacts/lists/{id}/contacts and map each row to a recipient object. You can combine list contacts with manually entered recipients in the same recipients array — deduplicate by phone before sending.

Send Text Message

POST/api/v1/send/text

Single Recipient

POST /api/v1/send/text
Authorization: Bearer <token>
Content-Type: application/json

{
  "message_id": "order_confirm_001",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "wa_number_id": "1",
  "callback_url": "https://your-app.com/webhooks/wa",
  "recipients": [
    {
      "recipient_id": "lead_5001",
      "phone": "0825551234",
      "name": "John"
    }
  ],
  "content": {
    "body": "Hi {{name}}, your order has been confirmed! We'll notify you when it ships."
  }
}

Response (200 OK)

{
  "success": true,
  "message_id": "order_confirm_001",
  "timestamp": "2026-07-03T14:30:00Z",
  "results": [
    {
      "recipient_id": "lead_5001",
      "phone": "27825551234",
      "wa_message_id": "wamid.HBgNMjc4MjU1NTEyMzQVAgA...",
      "status": "sent"
    }
  ]
}

POST/api/v1/send/text

Multiple Recipients (Batch)

Send the same message to multiple recipients in one API call. Each recipient gets a personalized message and an individual status in the response.

POST /api/v1/send/text
Authorization: Bearer <token>
Content-Type: application/json

{
  "message_id": "promo_batch_042",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "wa_number_id": "1",
  "callback_url": "https://your-app.com/webhooks/wa",
  "recipients": [
    { "recipient_id": "lead_101", "phone": "0821111111", "name": "Alice" },
    { "recipient_id": "lead_102", "phone": "0822222222", "name": "Bob" },
    { "recipient_id": "lead_103", "phone": "0823333333", "name": "Carol" }
  ],
  "content": {
    "body": "Hey {{name}}! Don't miss our special offer this weekend. Reply YES to learn more."
  }
}

Response (200 OK)

{
  "success": true,
  "message_id": "promo_batch_042",
  "timestamp": "2026-07-03T14:30:00Z",
  "results": [
    {
      "recipient_id": "lead_101",
      "phone": "27821111111",
      "wa_message_id": "wamid.HBgNMjc4MjExMTExMTEVAgA...",
      "status": "sent"
    },
    {
      "recipient_id": "lead_102",
      "phone": "27822222222",
      "wa_message_id": "wamid.HBgNMjc4MjIyMjIyMjIVAgA...",
      "status": "sent"
    },
    {
      "recipient_id": "lead_103",
      "phone": "27823333333",
      "status": "queued",
      "error": "Daily conversation limit reached for tier. Scheduled for 2026-07-04"
    }
  ]
}

Note: Each recipient is processed individually. Some may succeed while others are queued or fail. A 100ms delay is applied between recipients.

Send Image

POST/api/v1/send/image

Send an Image Message

Field	Type	Required	Description
content.image_url	string	Yes	Public URL of the image (JPEG, PNG)
content.caption	string	No	Optional caption (supports {{name}})

POST /api/v1/send/image
Authorization: Bearer <token>
Content-Type: application/json

{
  "message_id": "img_promo_007",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "wa_number_id": "1",
  "callback_url": "https://your-app.com/webhooks/wa",
  "recipients": [
    { "recipient_id": "lead_201", "phone": "0825551234", "name": "Sarah" }
  ],
  "content": {
    "image_url": "https://storage.googleapis.com/your-bucket/promo-banner.jpg",
    "caption": "Hi {{name}}, check out our latest deals!"
  }
}

Response (200 OK)

{
  "success": true,
  "message_id": "img_promo_007",
  "timestamp": "2026-07-03T14:35:00Z",
  "results": [
    {
      "recipient_id": "lead_201",
      "phone": "27825551234",
      "wa_message_id": "wamid.HBgNMjc4MjU1NTEyMzQVAgASGBI...",
      "status": "sent"
    }
  ]
}

Send Video

POST/api/v1/send/video

Send a Video Message

Field	Type	Required	Description
content.video_url	string	Yes	Public URL of the video (MP4, max 16MB)
content.caption	string	No	Optional caption (supports {{name}})

POST /api/v1/send/video
Authorization: Bearer <token>
Content-Type: application/json

{
  "message_id": "video_demo_003",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "wa_number_id": "1",
  "callback_url": "https://your-app.com/webhooks/wa",
  "recipients": [
    { "recipient_id": "lead_301", "phone": "0825551234", "name": "Mike" }
  ],
  "content": {
    "video_url": "https://storage.googleapis.com/your-bucket/demo-video.mp4",
    "caption": "{{name}}, here's a quick walkthrough of the new features"
  }
}

Response (200 OK)

{
  "success": true,
  "message_id": "video_demo_003",
  "timestamp": "2026-07-03T14:38:00Z",
  "results": [
    {
      "recipient_id": "lead_301",
      "phone": "27825551234",
      "wa_message_id": "wamid.HBgNMjc4MjU1NTEyMzQVAgASGBI...",
      "status": "sent"
    }
  ]
}

Send Document

POST/api/v1/send/document

Send a Document

Field	Type	Required	Description
content.document_url	string	Yes	Public URL of the document (PDF, DOCX, etc.)
content.filename	string	No	Display filename for the recipient
content.caption	string	No	Optional caption

POST /api/v1/send/document
Authorization: Bearer <token>
Content-Type: application/json

{
  "message_id": "invoice_send_099",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "wa_number_id": "1",
  "callback_url": "https://your-app.com/webhooks/wa",
  "recipients": [
    { "recipient_id": "customer_401", "phone": "0825551234", "name": "Lisa" }
  ],
  "content": {
    "document_url": "https://storage.googleapis.com/your-bucket/invoice-2026-099.pdf",
    "filename": "Invoice-2026-099.pdf",
    "caption": "Hi {{name}}, please find your invoice attached."
  }
}

Response (200 OK)

{
  "success": true,
  "message_id": "invoice_send_099",
  "timestamp": "2026-07-03T14:42:00Z",
  "results": [
    {
      "recipient_id": "customer_401",
      "phone": "27825551234",
      "wa_message_id": "wamid.HBgNMjc4MjU1NTEyMzQVAgASGBI...",
      "status": "sent"
    }
  ]
}

Send Audio

POST/api/v1/send/audio

Send an Audio/Voice Message

Field	Type	Required	Description
content.audio_url	string	Yes	Public URL of the audio file (MP3, OGG, AMR)

POST /api/v1/send/audio
Authorization: Bearer <token>
Content-Type: application/json

{
  "message_id": "audio_msg_001",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "wa_number_id": "1",
  "callback_url": "https://your-app.com/webhooks/wa",
  "recipients": [
    { "recipient_id": "lead_801", "phone": "0825551234", "name": "James" }
  ],
  "content": {
    "audio_url": "https://storage.googleapis.com/your-bucket/greeting.mp3"
  }
}

Response (200 OK)

{
  "success": true,
  "message_id": "audio_msg_001",
  "timestamp": "2026-07-03T15:00:00Z",
  "results": [
    {
      "recipient_id": "lead_801",
      "phone": "27825551234",
      "wa_message_id": "wamid.HBgNMjc4MjU1NTEyMzQVAgA...",
      "status": "sent"
    }
  ]
}

Send Location

POST/api/v1/send/location

Send a Location Pin

Field	Type	Required	Description
content.latitude	number	Yes	Latitude coordinate
content.longitude	number	Yes	Longitude coordinate
content.name	string	No	Location name (displayed as title)
content.address	string	No	Full address text

POST /api/v1/send/location
Authorization: Bearer <token>
Content-Type: application/json

{
  "message_id": "location_msg_001",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "wa_number_id": "1",
  "callback_url": "https://your-app.com/webhooks/wa",
  "recipients": [
    { "recipient_id": "cust_901", "phone": "0825551234", "name": "Anna" }
  ],
  "content": {
    "latitude": -33.9249,
    "longitude": 18.4241,
    "name": "Cape Town Showroom",
    "address": "123 Main Road, Cape Town, 8001"
  }
}

Response (200 OK)

{
  "success": true,
  "message_id": "location_msg_001",
  "timestamp": "2026-07-03T15:05:00Z",
  "results": [
    {
      "recipient_id": "cust_901",
      "phone": "27825551234",
      "wa_message_id": "wamid.HBgNMjc4MjU1NTEyMzQVAgA...",
      "status": "sent"
    }
  ]
}

Send Interactive: Buttons

Send a message with up to 3 reply buttons. When the user taps a button, you'll receive a callback with the button ID.

POST/api/v1/send/interactive

Reply Buttons (max 3)

Field	Type	Required	Description
content.type	string	Yes	Must be "buttons"
content.body	string	Yes	Message text above the buttons
content.buttons	array	Yes	1-3 button objects

POST /api/v1/send/interactive
Authorization: Bearer <token>
Content-Type: application/json

{
  "message_id": "confirm_appt_055",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "wa_number_id": "1",
  "callback_url": "https://your-app.com/webhooks/wa",
  "recipients": [
    { "recipient_id": "patient_501", "phone": "0825551234", "name": "David" }
  ],
  "content": {
    "type": "buttons",
    "body": "Hi {{name}}, you have an appointment tomorrow at 10:00 AM. Can you confirm?",
    "buttons": [
      { "type": "reply", "reply": { "id": "btn_confirm", "title": "Confirm" } },
      { "type": "reply", "reply": { "id": "btn_reschedule", "title": "Reschedule" } },
      { "type": "reply", "reply": { "id": "btn_cancel", "title": "Cancel" } }
    ]
  }
}

Response (200 OK)

{
  "success": true,
  "message_id": "confirm_appt_055",
  "timestamp": "2026-07-03T14:40:00Z",
  "results": [
    {
      "recipient_id": "patient_501",
      "phone": "27825551234",
      "wa_message_id": "wamid.HBgNMjc4MjU1NTEyMzQVAgASGBQ...",
      "status": "sent"
    }
  ]
}

Send Interactive: List

Send a list menu with sections and selectable items. The user taps a button to expand the list, then selects an option.

POST/api/v1/send/interactive

List with Sections

Field	Type	Required	Description
content.type	string	Yes	Must be "list"
content.body	string	Yes	Message text above the list
content.button_text	string	Yes	Text on the button that opens the list
content.sections	array	Yes	Array of section objects with rows

POST /api/v1/send/interactive
Authorization: Bearer <token>
Content-Type: application/json

{
  "message_id": "dept_select_012",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "wa_number_id": "1",
  "callback_url": "https://your-app.com/webhooks/wa",
  "recipients": [
    { "recipient_id": "customer_601", "phone": "0825551234", "name": "Emma" }
  ],
  "content": {
    "type": "list",
    "body": "Hi {{name}}, how can we help you today? Please select a department:",
    "button_text": "Choose Department",
    "sections": [
      {
        "title": "Sales",
        "rows": [
          { "id": "dept_new_car", "title": "New Vehicles", "description": "Enquire about new cars" },
          { "id": "dept_used_car", "title": "Used Vehicles", "description": "Browse pre-owned stock" }
        ]
      },
      {
        "title": "Support",
        "rows": [
          { "id": "dept_service", "title": "Service & Repairs", "description": "Book a service" },
          { "id": "dept_finance", "title": "Finance", "description": "Payment queries" }
        ]
      }
    ]
  }
}

Response (200 OK)

{
  "success": true,
  "message_id": "dept_select_012",
  "timestamp": "2026-07-03T14:45:00Z",
  "results": [
    {
      "recipient_id": "customer_601",
      "phone": "27825551234",
      "wa_message_id": "wamid.HBgNMjc4MjU1NTEyMzQVAgASGBQ...",
      "status": "sent"
    }
  ]
}

Interactive Message Limits

WAPit validates interactive payloads server-side before calling Meta. Requests that exceed these WhatsApp Cloud API limits return HTTP 400 with a VALIDATION_ERROR and field-specific details (e.g. content.buttons[0].title). If Meta still rejects a payload, error code 131009 is mapped to a friendly character-limit message.

Character & count limits (enforced on /api/v1/send/interactive)

Field	Max length / count
content.body	1,024 characters
content.buttons[].title	20 characters (max 3 buttons)
content.buttons[].id	256 characters
content.button_text	20 characters (list menu open button)
content.sections[].title	24 characters (max 10 sections)
content.sections[].rows[].title	24 characters
content.sections[].rows[].description	72 characters
content.sections[].rows[].id	200 characters (max 10 rows total across all sections)

Validation error example

{
  "success": false,
  "error": {
    "code": "VALIDATION_ERROR",
    "message": "Request validation failed",
    "details": [
      {
        "field": "content.buttons[0].title",
        "issue": "Button title must be 20 characters or fewer (got 28)"
      },
      {
        "field": "content.sections[0].options[1].description",
        "issue": "List row description must be 72 characters or fewer (got 95)"
      }
    ]
  }
}

Send Template Message

Send a pre-approved message template. Templates must be approved by Meta before use. Per-recipient components override the shared content.components.

POST/api/v1/send/template

Template with Variables

Field	Type	Required	Description
content.template_name	string	Yes	Meta-approved template name
content.language_code	string	Yes	Template language (e.g. "en_US", "en")
content.components	array	No	Shared template components (header, body vars)
recipients[].components	array	No	Per-recipient overrides (takes precedence)

POST /api/v1/send/template
Authorization: Bearer <token>
Content-Type: application/json

{
  "message_id": "reminder_batch_077",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "wa_number_id": "1",
  "callback_url": "https://your-app.com/webhooks/wa",
  "recipients": [
    {
      "recipient_id": "patient_701",
      "phone": "0825551234",
      "name": "John",
      "components": [
        {
          "type": "body",
          "parameters": [
            { "type": "text", "text": "John" },
            { "type": "text", "text": "Dr. Smith" },
            { "type": "text", "text": "10:00 AM, 5 July 2026" }
          ]
        }
      ]
    },
    {
      "recipient_id": "patient_702",
      "phone": "0826661234",
      "name": "Sarah",
      "components": [
        {
          "type": "body",
          "parameters": [
            { "type": "text", "text": "Sarah" },
            { "type": "text", "text": "Dr. Jones" },
            { "type": "text", "text": "2:30 PM, 5 July 2026" }
          ]
        }
      ]
    }
  ],
  "content": {
    "template_name": "appointment_reminder",
    "language_code": "en"
  }
}

Response (200 OK)

{
  "success": true,
  "message_id": "reminder_batch_077",
  "timestamp": "2026-07-03T14:50:00Z",
  "results": [
    {
      "recipient_id": "patient_701",
      "phone": "27825551234",
      "wa_message_id": "wamid.HBgNMjc4MjU1NTEyMzQVAgA...",
      "status": "sent"
    },
    {
      "recipient_id": "patient_702",
      "phone": "27826661234",
      "wa_message_id": "wamid.HBgNMjc4MjY2NjEyMzQVAgA...",
      "status": "sent"
    }
  ]
}

Contact List Management

Create and manage contact lists scoped to a campaign. Use lists to store recipient phone numbers for bulk messaging. Contacts are normalized to international format on insert.

GET/api/v1/contacts/lists?campaign_id=X

List Contact Lists

GET /api/v1/contacts/lists?campaign_id=carleads_main
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "lists": [
    {
      "id": "a1b2c3d4-e5f6-7890-abcd-ef1234567890",
      "company_id": "comp_carleads_abc123",
      "campaign_id": "carleads_main",
      "name": "Newsletter Subscribers",
      "description": "Monthly promo list",
      "contact_count": 150,
      "is_active": true,
      "created_at": "2026-07-01T10:00:00Z",
      "updated_at": "2026-07-03T12:00:00Z"
    }
  ],
  "count": 1
}

POST/api/v1/contacts/lists

Create Contact List

Field	Type	Required	Description
company_id	string	Yes	Company identifier
campaign_id	string	Yes	Campaign slug
name	string	Yes	List display name
description	string	No	Optional description

POST /api/v1/contacts/lists
Authorization: Bearer <token>
Content-Type: application/json

{
  "company_id": "comp_carleads_abc123",
  "campaign_id": "carleads_main",
  "name": "VIP Customers",
  "description": "High-value repeat buyers"
}

Response (201 Created)

{
  "success": true,
  "list": {
    "id": "b2c3d4e5-f6a7-8901-bcde-f12345678901",
    "company_id": "comp_carleads_abc123",
    "campaign_id": "carleads_main",
    "name": "VIP Customers",
    "description": "High-value repeat buyers",
    "contact_count": 0,
    "is_active": true,
    "created_at": "2026-07-03T15:00:00Z",
    "updated_at": "2026-07-03T15:00:00Z"
  }
}

GET/api/v1/contacts/lists/{id}

Get Contact List

GET /api/v1/contacts/lists/b2c3d4e5-f6a7-8901-bcde-f12345678901
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "list": {
    "id": "b2c3d4e5-f6a7-8901-bcde-f12345678901",
    "company_id": "comp_carleads_abc123",
    "campaign_id": "carleads_main",
    "name": "VIP Customers",
    "description": "High-value repeat buyers",
    "contact_count": 42,
    "is_active": true,
    "created_at": "2026-07-03T15:00:00Z",
    "updated_at": "2026-07-03T16:00:00Z"
  }
}

PUT/api/v1/contacts/lists/{id}

Update Contact List

PUT /api/v1/contacts/lists/b2c3d4e5-f6a7-8901-bcde-f12345678901
Authorization: Bearer <token>
Content-Type: application/json

{
  "name": "VIP Customers (Updated)",
  "description": "Premium tier subscribers"
}

Response (200 OK)

{
  "success": true,
  "list": {
    "id": "b2c3d4e5-f6a7-8901-bcde-f12345678901",
    "name": "VIP Customers (Updated)",
    "description": "Premium tier subscribers",
    "contact_count": 42,
    "updated_at": "2026-07-03T16:30:00Z"
  }
}

DELETE/api/v1/contacts/lists/{id}

Delete Contact List

Permanently deletes the list and all contacts (CASCADE).

DELETE /api/v1/contacts/lists/b2c3d4e5-f6a7-8901-bcde-f12345678901
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "message": "Contact list deleted"
}

GET/api/v1/contacts/lists/{id}/contacts?limit=50&offset=0&search=term

List Contacts in a List

Field	Type	Required	Description
limit	integer	No	Page size (default: 50)
offset	integer	No	Pagination offset (default: 0)
search	string	No	Filter by phone or name (ILIKE)

GET /api/v1/contacts/lists/b2c3d4e5-f6a7-8901-bcde-f12345678901/contacts?limit=50&offset=0&search=john
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "contacts": [
    {
      "id": "c3d4e5f6-a7b8-9012-cdef-123456789012",
      "contact_list_id": "b2c3d4e5-f6a7-8901-bcde-f12345678901",
      "phone": "27821234567",
      "name": "John Smith",
      "email": "john@example.com",
      "is_active": true,
      "created_at": "2026-07-03T15:10:00Z",
      "updated_at": "2026-07-03T15:10:00Z"
    }
  ],
  "total": 42
}

POST/api/v1/contacts/lists/{id}/contacts

Add Contacts (Batch)

Batch insert contacts. Optional duplicate_mode: warn (409 with duplicates), skip, or proceed. Duplicate phones within the same list are upserted.

POST /api/v1/contacts/lists/b2c3d4e5-f6a7-8901-bcde-f12345678901/contacts
Authorization: Bearer <token>
Content-Type: application/json

{
  "campaign_id": "carleads_main",
  "duplicate_mode": "warn",
  "contacts": [
    { "phone": "0821234567", "name": "John Smith", "email": "john@example.com" },
    { "phone": "27821234568", "name": "Jane Doe", "email": "jane@example.com" }
  ]
}

Response (200 OK)

{
  "success": true,
  "added": 1,
  "updated": 1
}

POST/api/v1/contacts/lists/{id}/contacts/import

Import Contacts from CSV

Import contacts from CSV data. Expected columns: phone,name,email. Optional duplicate_mode: warn, skip, or proceed.

POST /api/v1/contacts/lists/b2c3d4e5-f6a7-8901-bcde-f12345678901/contacts/import
Authorization: Bearer <token>
Content-Type: application/json

{
  "csv_data": "phone,name,email\n27821234567,John Smith,john@example.com\n27821234568,Jane Doe,jane@example.com",
  "duplicate_mode": "skip"
}

Response (200 OK)

{
  "success": true,
  "imported": 2,
  "skipped": 0,
  "errors": []
}

GET/api/v1/contacts/lists/{id}/contacts/export

Export Contacts to CSV

Download all contacts in a list as CSV (phone,name,email).

GET /api/v1/contacts/lists/b2c3d4e5-f6a7-8901-bcde-f12345678901/contacts/export
Authorization: Bearer <token>

Response (200 OK)

Returns text/csv with header row and one contact per line.

phone,name,email
27821234567,John Smith,john@example.com
27821234568,Jane Doe,jane@example.com

PUT/api/v1/contacts/lists/{id}/contacts/{contact_id}

Update Contact

PUT /api/v1/contacts/lists/b2c3d4e5-f6a7-8901-bcde-f12345678901/contacts/c3d4e5f6-a7b8-9012-cdef-123456789012
Authorization: Bearer <token>
Content-Type: application/json

{
  "phone": "27821234567",
  "name": "John Smith Jr.",
  "email": "john.jr@example.com",
  "metadata_json": "{\"source\": \"import\"}"
}

Response (200 OK)

{
  "success": true,
  "contact": {
    "id": "c3d4e5f6-a7b8-9012-cdef-123456789012",
    "phone": "27821234567",
    "name": "John Smith Jr.",
    "email": "john.jr@example.com",
    "updated_at": "2026-07-03T16:45:00Z"
  }
}

DELETE/api/v1/contacts/lists/{id}/contacts/{contact_id}

Delete Contact

DELETE /api/v1/contacts/lists/b2c3d4e5-f6a7-8901-bcde-f12345678901/contacts/c3d4e5f6-a7b8-9012-cdef-123456789012
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "message": "Contact deleted"
}

Saved Message Templates

Store reusable message templates locally (not Meta WABA templates). Templates support all message types: text, buttons, list, image, video, document, audio, location, and WhatsApp template payloads. The content_json field stores type-specific payload data matching the send endpoint format.

GET/api/v1/saved-messages?customer_profile_id=X&type=Y&include_shared=true

List Saved Messages

Optional type filter. Pass include_shared=true (default) to include platform templates with scope='shared'.

Field	Type	Required	Description
customer_profile_id	string	Yes	Customer profile ID (query parameter)
type	string	No	Filter by type: text, buttons, list, image, video, document, audio, location, wa_template

GET /api/v1/saved-messages?customer_profile_id=clxyz123&type=buttons
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "messages": [
    {
      "id": "msg_abc123",
      "customer_profile_id": "clxyz123",
      "company_id": "comp_carleads_abc123",
      "campaign_id": "carleads_main",
      "name": "Appointment Confirm",
      "category": "utility",
      "type": "buttons",
      "body": "Hi {{name}}, can you confirm your appointment?",
      "content_json": "{\"type\":\"buttons\",\"buttons\":[{\"id\":\"confirm\",\"title\":\"Confirm\"}]}",
      "is_active": true,
      "created_at": "2026-07-01T10:00:00Z",
      "updated_at": "2026-07-03T12:00:00Z"
    }
  ],
  "count": 1
}

POST/api/v1/saved-messages

Create Saved Message

Field	Type	Required	Description
customer_profile_id	string	Yes	Customer profile ID
company_id	string	No	Company identifier
campaign_id	string	No	Campaign slug
name	string	Yes	Template display name
category	string	No	Category label (default: general)
type	string	Yes	Message type (see list endpoint)
body	string	Yes	Message body or description
content_json	string	No	Type-specific JSON payload

POST /api/v1/saved-messages
Authorization: Bearer <token>
Content-Type: application/json

{
  "customer_profile_id": "clxyz123",
  "company_id": "comp_carleads_abc123",
  "campaign_id": "carleads_main",
  "name": "Store Location",
  "category": "utility",
  "type": "location",
  "body": "Visit our showroom",
  "content_json": "{\"latitude\":-33.9249,\"longitude\":18.4241,\"name\":\"Cape Town Showroom\",\"address\":\"123 Main Road, Cape Town\"}"
}

Response (201 Created)

{
  "success": true,
  "message": {
    "id": "msg_def456",
    "customer_profile_id": "clxyz123",
    "name": "Store Location",
    "type": "location",
    "body": "Visit our showroom",
    "is_active": true,
    "created_at": "2026-07-03T15:00:00Z"
  }
}

GET/api/v1/saved-messages/{id}

Get Saved Message

GET /api/v1/saved-messages/msg_def456
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "message": {
    "id": "msg_def456",
    "customer_profile_id": "clxyz123",
    "name": "Store Location",
    "type": "location",
    "body": "Visit our showroom",
    "content_json": "{\"latitude\":-33.9249,\"longitude\":18.4241,\"name\":\"Cape Town Showroom\",\"address\":\"123 Main Road\"}",
    "is_active": true,
    "created_at": "2026-07-03T15:00:00Z",
    "updated_at": "2026-07-03T15:00:00Z"
  }
}

PUT/api/v1/saved-messages/{id}

Update Saved Message

PUT /api/v1/saved-messages/msg_def456
Authorization: Bearer <token>
Content-Type: application/json

{
  "name": "Store Location (Updated)",
  "category": "marketing",
  "type": "location",
  "body": "Find us here",
  "content_json": "{\"latitude\":-33.9249,\"longitude\":18.4241,\"name\":\"Cape Town Showroom\",\"address\":\"456 New Street\"}"
}

Response (200 OK)

{
  "success": true,
  "message": {
    "id": "msg_def456",
    "name": "Store Location (Updated)",
    "body": "Find us here",
    "updated_at": "2026-07-03T16:00:00Z"
  }
}

DELETE/api/v1/saved-messages/{id}

Delete Saved Message

Soft-deletes the template (sets is_active to false).

DELETE /api/v1/saved-messages/msg_def456
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "message": "Saved message deleted"
}

content_json Structure by Type

Type	content_json
text	null (body field is sufficient)
buttons	{"type":"buttons","body":"...","buttons":[{"type":"reply","reply":{"id":"x","title":"Y"}}]}
list	{"type":"list","body":"...","button_text":"View","sections":[{"title":"S","rows":[{"id":"x","title":"Y","description":"Z"}]}]}
image	{"image_url":"https://...","caption":"text"}
video	{"video_url":"https://...","caption":"text"}
document	{"document_url":"https://...","filename":"file.pdf","caption":"text"}
audio	{"audio_url":"https://..."}
location	{"latitude":-33.9,"longitude":18.4,"name":"Place","address":"123 St"}
wa_template	{"template_name":"opt_in","language_code":"en","components":[...]}

Message Scheduling

Schedule messages to send at a future time. Target a contact list, explicit phone numbers, or both. Call POST /scheduled-messages/process to dispatch all due pending messages.

GET/api/v1/scheduled-messages?company_id=X&status=pending

List Scheduled Messages

GET /api/v1/scheduled-messages?company_id=comp_abc&status=pending
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "scheduled_messages": [
    {
      "id": "sched_001",
      "company_id": "comp_abc",
      "campaign_id": "carleads_main",
      "wa_credential_id": "cred_123",
      "contact_list_id": "list_uuid",
      "message_type": "text",
      "body": "Hi {{name}}, reminder for tomorrow!",
      "scheduled_at": "2026-07-06T09:00:00Z",
      "status": "pending",
      "sent_count": 0,
      "failed_count": 0
    }
  ],
  "count": 1
}

POST/api/v1/scheduled-messages

Schedule a Message

POST /api/v1/scheduled-messages
Authorization: Bearer <token>
Content-Type: application/json

{
  "company_id": "comp_abc",
  "campaign_id": "carleads_main",
  "wa_credential_id": "cred_123",
  "customer_profile_id": "clxyz123",
  "contact_list_id": "list_uuid",
  "message_type": "text",
  "body": "Hi {{name}}, your appointment is tomorrow at 10am.",
  "scheduled_at": "2026-07-06T09:00:00Z"
}

Response (201 Created)

{
  "success": true,
  "scheduled_message": {
    "id": "sched_001",
    "status": "pending",
    "scheduled_at": "2026-07-06T09:00:00Z"
  }
}

GET/api/v1/scheduled-messages/{id}

Get Scheduled Message

GET /api/v1/scheduled-messages/sched_001
Authorization: Bearer <token>

PUT/api/v1/scheduled-messages/{id}

Update Scheduled Message

Update a pending scheduled message. Only messages with status pending can be modified.

PUT /api/v1/scheduled-messages/sched_001
Authorization: Bearer <token>
Content-Type: application/json

{
  "scheduled_at": "2026-07-07T09:00:00Z",
  "body": "Hi {{name}}, updated reminder for tomorrow!",
  "contact_list_id": "list_uuid"
}

POST/api/v1/scheduled-messages/process

Process Due Scheduled Messages

POST /api/v1/scheduled-messages/process
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "processed": 3,
  "sent": 145,
  "failed": 2
}

DELETE/api/v1/scheduled-messages/{id}

Cancel Scheduled Message

DELETE /api/v1/scheduled-messages/sched_001
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "message": "Scheduled message cancelled successfully"
}

Campaign Analytics

Track message batches and aggregate delivery metrics. Link individual sends to a batch via batch_id on message_log.

GET/api/v1/analytics/summary?company_id=X&period=7d

Analytics Summary

Period: 7d, 30d, or 90d.

GET /api/v1/analytics/summary?company_id=comp_abc&period=30d
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "summary": {
    "total_batches": 12,
    "total_messages": 4500,
    "total_delivered": 4200,
    "total_read": 3100,
    "total_failed": 45,
    "delivery_rate": 93.3,
    "read_rate": 73.8
  }
}

GET/api/v1/analytics/batches?company_id=X&campaign_id=Y

List Message Batches

GET /api/v1/analytics/batches?company_id=comp_abc&campaign_id=carleads_main
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "batches": [
    {
      "id": "batch_001",
      "name": "July Promo",
      "message_type": "text",
      "total_recipients": 500,
      "sent_count": 500,
      "delivered_count": 480,
      "read_count": 320,
      "failed_count": 5,
      "status": "completed"
    }
  ],
  "count": 1
}

GET/api/v1/analytics/batches/{id}

Get Message Batch

GET /api/v1/analytics/batches/batch_001
Authorization: Bearer <token>

POST/api/v1/analytics/batches

Create Message Batch

POST /api/v1/analytics/batches
Authorization: Bearer <token>
Content-Type: application/json

{
  "company_id": "comp_abc",
  "campaign_id": "carleads_main",
  "wa_credential_id": "cred_123",
  "name": "July Promo",
  "message_type": "text",
  "total_recipients": 500
}

Response (201 Created)

{
  "success": true,
  "batch_id": "batch_001",
  "batch": { "id": "batch_001", "status": "in_progress" }
}

PUT/api/v1/analytics/batches/{id}/counts

Update Batch Counts

PUT /api/v1/analytics/batches/batch_001/counts
Authorization: Bearer <token>
Content-Type: application/json

{
  "sent_count": 500,
  "delivered_count": 480,
  "read_count": 320,
  "failed_count": 5,
  "status": "completed"
}

Shared Templates

Platform-wide templates (scope='shared') managed by admins. Customers see them alongside their own templates via GET /saved-messages?include_shared=true.

GET/api/v1/admin/shared-templates?type=X

List Shared Templates

GET /api/v1/admin/shared-templates?type=buttons
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "templates": [
    {
      "id": "tmpl_shared_001",
      "name": "Welcome Message",
      "type": "text",
      "scope": "shared",
      "body": "Welcome to our platform!"
    }
  ],
  "count": 1
}

POST/api/v1/admin/shared-templates

Create Shared Template

POST /api/v1/admin/shared-templates
Authorization: Bearer <token>
Content-Type: application/json

{
  "name": "Appointment Reminder",
  "type": "buttons",
  "category": "utility",
  "body": "Hi {{name}}, please confirm your appointment.",
  "content_json": "{\"type\":\"buttons\",\"buttons\":[{\"type\":\"reply\",\"reply\":{\"id\":\"confirm\",\"title\":\"Confirm\"}}]}"
}

Response (201 Created)

{
  "success": true,
  "template": { "id": "tmpl_shared_002", "scope": "shared", "name": "Appointment Reminder" }
}

GET/api/v1/admin/shared-templates/{id}

Get Shared Template

GET /api/v1/admin/shared-templates/tmpl_shared_001
Authorization: Bearer <token>

PUT/api/v1/admin/shared-templates/{id}

Update Shared Template

PUT /api/v1/admin/shared-templates/tmpl_shared_001
Authorization: Bearer <token>
Content-Type: application/json

{
  "name": "Welcome Message (Updated)",
  "body": "Welcome! We're glad you're here.",
  "content_json": "{\"type\":\"text\"}"
}

DELETE/api/v1/admin/shared-templates/{id}

Delete Shared Template

DELETE /api/v1/admin/shared-templates/tmpl_shared_001
Authorization: Bearer <token>

Contact Tags

Tag contacts for segmentation. Tags are scoped to a company. Assign tags to individual contacts for filtering and targeted sends.

GET/api/v1/tags?company_id=X

List Tags

GET /api/v1/tags?company_id=comp_abc
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "tags": [
    {
      "id": "tag_001",
      "company_id": "comp_abc",
      "name": "VIP",
      "color": "#10B981",
      "contact_count": 42
    }
  ],
  "count": 1
}

POST/api/v1/tags

Create Tag

POST /api/v1/tags
Authorization: Bearer <token>
Content-Type: application/json

{
  "company_id": "comp_abc",
  "name": "VIP",
  "color": "#10B981"
}

Response (201 Created)

{
  "success": true,
  "tag": { "id": "tag_001", "name": "VIP", "color": "#10B981" }
}

PUT/api/v1/tags/{id}

Update Tag

PUT /api/v1/tags/tag_001
Authorization: Bearer <token>
Content-Type: application/json

{
  "name": "VIP Premium",
  "color": "#059669"
}

DELETE/api/v1/tags/{id}

Delete Tag

DELETE /api/v1/tags/tag_001?company_id=comp_abc
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "message": "Tag deleted"
}

GET/api/v1/contacts/{contact_id}/tags

Get Contact Tags

GET /api/v1/contacts/contact_uuid/tags
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "tags": [
    { "id": "tag_001", "name": "VIP", "color": "#10B981" }
  ]
}

POST/api/v1/contacts/{contact_id}/tags

Assign Tags to Contact

POST /api/v1/contacts/contact_uuid/tags
Authorization: Bearer <token>
Content-Type: application/json

{
  "tag_ids": ["tag_001", "tag_002"]
}

Response (200 OK)

{
  "success": true,
  "message": "Tags assigned successfully",
  "assigned": 2
}

GET/api/v1/tags/{id}/contacts?company_id=X

List Contacts by Tag

GET /api/v1/tags/tag_001/contacts?company_id=comp_abc
Authorization: Bearer <token>

DELETE/api/v1/contacts/{contact_id}/tags/{tag_id}

Remove Tag from Contact

DELETE /api/v1/contacts/contact_uuid/tags/tag_001
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "message": "Tag removed from contact"
}

Duplicate Detection

Detect phone numbers that already exist in other contact lists within the same company. Use duplicate_mode on add/import: warn (409 with duplicates), skip, or proceed.

POST/api/v1/contacts/duplicates/check

Check Duplicates Before Import

POST /api/v1/contacts/duplicates/check
Authorization: Bearer <token>
Content-Type: application/json

{
  "company_id": "comp_abc",
  "target_list_id": "list_uuid",
  "phones": ["0825551234", "0826667890"]
}

Response (200 OK)

{
  "success": true,
  "duplicates": [
    {
      "id": "contact_uuid",
      "phone": "27825551234",
      "name": "John",
      "list_id": "other_list_uuid",
      "list_name": "Newsletter Subscribers"
    }
  ],
  "total": 1
}

GET/api/v1/contacts/duplicates?company_id=X

Find All Duplicates

GET /api/v1/contacts/duplicates?company_id=comp_abc
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "duplicates": [
    {
      "phone": "27825551234",
      "name": "John",
      "list_count": 2,
      "lists": ["VIP Customers", "Newsletter Subscribers"]
    }
  ],
  "total": 1
}

Send Reaction

React to a specific message with an emoji. This does not use the standard recipient/content format — it targets a specific WhatsApp message by its wa_message_id.

POST/api/v1/send/reaction

React to a Message

Field	Type	Required	Description
campaign_id	string	Yes	Campaign slug
wa_number_id	number	Yes	WA number to send from
message_id	string	Yes	The wa_message_id of the message to react to
emoji	string	Yes	Emoji character (e.g. "👍", "❤️")

POST /api/v1/send/reaction
Authorization: Bearer <token>
Content-Type: application/json

{
  "campaign_id": "carleads_main",
  "wa_number_id": 1,
  "message_id": "wamid.HBgNMjc4MjU1NTEyMzQVAgA...",
  "emoji": "👍"
}

Response (200 OK)

{
  "success": true,
  "message": "Reaction sent"
}

Mark as Read

Send a read receipt for a specific message. This shows the sender that you've read their message (blue ticks).

POST/api/v1/messages/read

Mark Message as Read

Field	Type	Required	Description
campaign_id	string	Yes	Campaign slug
wa_number_id	number	Yes	WA number that received the message
message_id	string	Yes	The wa_message_id to mark as read

POST /api/v1/messages/read
Authorization: Bearer <token>
Content-Type: application/json

{
  "campaign_id": "carleads_main",
  "wa_number_id": 1,
  "message_id": "wamid.HBgNMjc4MjU1NTEyMzQVAgA..."
}

Response (200 OK)

{
  "success": true,
  "message": "Message marked as read"
}

Template Management

Manage your Meta WABA message templates. Templates must be submitted to Meta for approval before they can be used with /send/template. These endpoints interact directly with the Meta Business API.

GET/api/v1/templates

List Templates

Field	Type	Required	Description
campaign_id	string	Yes	Campaign slug (query parameter)
wa_number_id	number	Yes	WA number ID (query parameter)

GET /api/v1/templates?campaign_id=carleads_main&wa_number_id=1
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "templates": [
    {
      "id": "local-uuid-001",
      "meta_template_id": "123456789",
      "name": "appointment_reminder",
      "status": "APPROVED",
      "category": "UTILITY",
      "language": "en_US",
      "components": [
        { "type": "BODY", "text": "Hi {{1}}, your appointment with {{2}} is at {{3}}." }
      ],
      "synced_at": "2026-07-03T14:00:00Z"
    },
    {
      "id": "local-uuid-002",
      "meta_template_id": "987654321",
      "name": "order_confirmation",
      "status": "PENDING",
      "category": "UTILITY",
      "language": "en_US",
      "components": [
        { "type": "BODY", "text": "Hi {{1}}, your order {{2}} has been confirmed." }
      ],
      "synced_at": "2026-07-03T14:00:00Z"
    }
  ],
  "count": 2
}

POST/api/v1/templates

Create Template

Submit a new template to Meta for approval. Templates typically take 24-48 hours to be reviewed. Status updates are received via webhook.

Field	Type	Required	Description
campaign_id	string	Yes	Campaign slug
wa_number_id	number	Yes	WA number ID
name	string	Yes	Template name (lowercase, underscores only)
category	string	Yes	UTILITY, MARKETING, or AUTHENTICATION
language	string	No	Language code (default: en_US)
components	array	Yes	Template components (HEADER, BODY, FOOTER, BUTTONS)

POST /api/v1/templates
Authorization: Bearer <token>
Content-Type: application/json

{
  "campaign_id": "carleads_main",
  "wa_number_id": 1,
  "name": "order_confirmation",
  "category": "UTILITY",
  "language": "en_US",
  "components": [
    {
      "type": "BODY",
      "text": "Hi {{1}}, your order {{2}} has been confirmed. Expected delivery: {{3}}."
    }
  ]
}

Response (201 Created)

{
  "success": true,
  "template": {
    "id": "123456789",
    "name": "order_confirmation",
    "status": "PENDING",
    "category": "UTILITY"
  },
  "message": "Template submitted for approval"
}

PUT/api/v1/templates/{template_id}

Edit Template

Update an existing Meta template by its meta_template_id. Edited templates return to PENDING status until Meta re-reviews them.

PUT /api/v1/templates/123456789
Authorization: Bearer <token>
Content-Type: application/json

{
  "campaign_id": "carleads_main",
  "wa_number_id": "1",
  "category": "UTILITY",
  "components": [
    {
      "type": "BODY",
      "text": "Hi {{1}}, your order {{2}} has shipped. Track it here: {{3}}."
    }
  ]
}

Response (200 OK)

{
  "success": true,
  "meta_template_id": "123456789",
  "status": "PENDING",
  "message": "Template updated. It will be re-reviewed by Meta."
}

POST/api/v1/templates/sync

Sync Templates from Meta

Force-sync all templates from Meta to the local cache. Useful after making changes directly in Meta Business Manager.

POST /api/v1/templates/sync?campaign_id=carleads_main&wa_number_id=1
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "synced": 5,
  "message": "Templates synced successfully"
}

DELETE/api/v1/templates/{name}

Delete Template

Delete a template from Meta. This permanently removes it and it cannot be recovered.

DELETE /api/v1/templates/order_confirmation?campaign_id=carleads_main&wa_number_id=1
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "message": "Template deleted"
}

Media Upload

Upload media files to Meta for use in messages. Returns a media_id that can be used as an alternative to public URLs in send/image, send/video, send/document, and send/audio endpoints.

POST/api/v1/media/upload

Upload Media File

Field	Type	Required	Description
file	binary	Yes	The media file (multipart/form-data)
campaign_id	string	Yes	Campaign slug (form field)
wa_number_id	string	Yes	WA number ID (form field)

Supported formats: JPEG, PNG, MP4, PDF, DOCX, MP3, OGG, AMR (max 16MB for video/audio, 100MB for documents)

POST /api/v1/media/upload
Authorization: Bearer <token>
Content-Type: multipart/form-data

------boundary
Content-Disposition: form-data; name="campaign_id"

carleads_main
------boundary
Content-Disposition: form-data; name="wa_number_id"

1
------boundary
Content-Disposition: form-data; name="file"; filename="invoice.pdf"
Content-Type: application/pdf

<binary file data>
------boundary--

Response (200 OK)

{
  "success": true,
  "media_id": "1234567890",
  "message": "Media uploaded successfully"
}

Usage: Use the returned media_id in your send requests instead of a public URL. Media IDs are valid for 30 days.

Business Profile

View and update your WhatsApp Business profile information. This controls what users see when they view your business details on WhatsApp.

GET/api/v1/profile

Get Business Profile

Field	Type	Required	Description
campaign_id	string	Yes	Campaign slug (query parameter)
wa_number_id	number	Yes	WA number ID (query parameter)

GET /api/v1/profile?campaign_id=carleads_main&wa_number_id=1
Authorization: Bearer <token>

Response (200 OK)

{
  "success": true,
  "profile": {
    "about": "We sell premium vehicles",
    "address": "123 Main Road, Cape Town",
    "description": "Trusted car dealership since 1990",
    "email": "info@carleads.co.za",
    "vertical": "AUTO",
    "websites": ["https://carleads.co.za"],
    "profile_picture_url": "https://..."
  }
}

PUT/api/v1/profile

Update Business Profile

Field	Type	Required	Description
campaign_id	string	Yes	Campaign slug
wa_number_id	number	Yes	WA number ID
about	string	No	Short business description (139 chars max)
address	string	No	Business address
description	string	No	Full business description (512 chars max)
email	string	No	Business email
vertical	string	No	Business category (AUTO, BEAUTY, RETAIL, etc.)
websites	array	No	Up to 2 website URLs

PUT /api/v1/profile
Authorization: Bearer <token>
Content-Type: application/json

{
  "campaign_id": "carleads_main",
  "wa_number_id": 1,
  "about": "SA's #1 car dealership",
  "address": "456 New Street, Cape Town, 8001",
  "description": "Premium new and pre-owned vehicles with nationwide delivery",
  "email": "hello@carleads.co.za",
  "vertical": "AUTO",
  "websites": ["https://carleads.co.za"]
}

Response (200 OK)

{
  "success": true,
  "message": "Profile updated successfully"
}

Callbacks & Webhooks

WAPit sends POST requests to your callback_url for every status change and incoming reply. Each callback includes the original message_id and recipient_id you sent, so you can link events back to your records.

Your endpoint must respond within 10 seconds with any 2xx status code. Failed callbacks are logged but not retried.

Outbound: Delivery Status Updates

Meta sends delivery events to WAPit; WAPit forwards them to your callback_url as event_type: status_update with statuses sent, delivered, read, or failed.

Inbound: User Replies & Incoming Messages

When a recipient replies (text, button tap, list selection, or media), WAPit POSTs event_type: user_reply to your callback. Media replies send an immediate callback with media_status: processing, then a second event_type: media_ready callback once the file is stored in cloud storage. You can also poll GET /api/v1/client/incoming for message history.

Status Update: Sent

Received immediately after the message is accepted by Meta.

POST https://your-app.com/webhooks/wa
Content-Type: application/json

{
  "event_type": "status_update",
  "message_id": "order_confirm_001",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "recipient_id": "lead_5001",
  "recipient_phone": "27825551234",
  "wa_message_id": "wamid.HBgNMjc4MjU1NTEyMzQVAgA...",
  "status": "sent",
  "timestamp": "2026-07-03T14:30:01Z"
}

Status Update: Delivered

The message reached the recipient's device.

{
  "event_type": "status_update",
  "message_id": "order_confirm_001",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "recipient_id": "lead_5001",
  "recipient_phone": "27825551234",
  "wa_message_id": "wamid.HBgNMjc4MjU1NTEyMzQVAgA...",
  "status": "delivered",
  "timestamp": "2026-07-03T14:30:05Z"
}

Status Update: Read

The recipient opened and read the message (blue ticks).

{
  "event_type": "status_update",
  "message_id": "order_confirm_001",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "recipient_id": "lead_5001",
  "recipient_phone": "27825551234",
  "wa_message_id": "wamid.HBgNMjc4MjU1NTEyMzQVAgA...",
  "status": "read",
  "timestamp": "2026-07-03T14:31:22Z"
}

Status Update: Failed

The message could not be delivered. Includes error details from Meta.

{
  "event_type": "status_update",
  "message_id": "promo_batch_042",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "recipient_id": "lead_103",
  "recipient_phone": "27823333333",
  "wa_message_id": "wamid.HBgNMjc4MjMzMzMzMzMVAgA...",
  "status": "failed",
  "timestamp": "2026-07-03T14:30:12Z",
  "error": {
    "code": 131026,
    "title": "Message undeliverable",
    "message": "The recipient phone number is not a valid WhatsApp number"
  }
}

User Reply: Text

The recipient typed a text reply to your message.

{
  "event_type": "user_reply",
  "incoming_message_id": "f47ac10b-58cc-4372-a567-0e02b2c3d479",
  "original_message_id": "uuid-of-message-log-row",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "recipient_id": "lead_5001",
  "sender_phone": "27825551234",
  "sender_name": "John",
  "wa_message_id": "wamid.inbound_abc123",
  "timestamp": "2026-07-03T14:35:00Z",
  "reply": {
    "type": "text",
    "body": "Yes, I'd like to know more about the offer"
  }
}

User Reply: Button Tap

The recipient tapped one of the reply buttons you sent.

{
  "event_type": "user_reply",
  "incoming_message_id": "a1b2c3d4-e5f6-7890-abcd-ef1234567890",
  "original_message_id": "uuid-of-message-log-row",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "recipient_id": "patient_501",
  "sender_phone": "27825551234",
  "sender_name": "David",
  "wa_message_id": "wamid.inbound_btn456",
  "timestamp": "2026-07-03T14:42:00Z",
  "reply": {
    "type": "button",
    "button_id": "btn_confirm",
    "button_title": "Confirm"
  }
}

User Reply: List Selection

The recipient selected an item from a list message.

{
  "event_type": "user_reply",
  "incoming_message_id": "b2c3d4e5-f6a7-8901-bcde-f12345678901",
  "original_message_id": "uuid-of-message-log-row",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "recipient_id": "customer_601",
  "sender_phone": "27825551234",
  "sender_name": "Emma",
  "wa_message_id": "wamid.inbound_list789",
  "timestamp": "2026-07-03T14:45:00Z",
  "reply": {
    "type": "list_selection",
    "selected_id": "dept_new_car",
    "selected_title": "New Vehicles"
  }
}

User Reply: Media (Processing)

The recipient sent an image/video/document. You'll receive this immediately (media still uploading to cloud storage).

{
  "event_type": "user_reply",
  "incoming_message_id": "c3d4e5f6-a7b8-9012-cdef-123456789012",
  "original_message_id": "uuid-of-message-log-row",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "recipient_id": "lead_5001",
  "sender_phone": "27825551234",
  "sender_name": "John",
  "wa_message_id": "wamid.inbound_img101",
  "timestamp": "2026-07-03T14:50:00Z",
  "media_status": "processing",
  "reply": {
    "type": "image",
    "media_id": "1234567890",
    "mime_type": "image/jpeg",
    "media_url": ""
  }
}

Media Ready

Sent after the media file has been downloaded from Meta and uploaded to cloud storage. The media_url is now a permanent link.

{
  "event_type": "media_ready",
  "incoming_message_id": "c3d4e5f6-a7b8-9012-cdef-123456789012",
  "original_message_id": "uuid-of-message-log-row",
  "client_id": "carleads",
  "campaign_id": "carleads_main",
  "recipient_id": "lead_5001",
  "sender_phone": "27825551234",
  "sender_name": "John",
  "wa_message_id": "wamid.inbound_img101",
  "timestamp": "2026-07-03T14:50:08Z",
  "media_status": "ready",
  "reply": {
    "type": "image",
    "media_id": "1234567890",
    "mime_type": "image/jpeg",
    "media_url": "https://storage.googleapis.com/wowresults.appspot.com/filestorage/1234567890.jpg"
  }
}

Message Queued (Tier Limit)

Your daily conversation limit has been reached. The message is queued and will be sent the next day.

{
  "event_type": "message_queued_tier_limit",
  "message_id": "promo_batch_042",
  "recipient_id": "lead_103",
  "phone": "27823333333",
  "reason": "Daily conversation limit reached for company tier",
  "tier": "tier_1",
  "daily_limit": 1000,
  "current_count": 1000,
  "scheduled_for": "2026-07-04",
  "timestamp": "2026-07-03T14:30:10Z"
}

Error Handling

All errors follow a consistent format with a machine-readable code, human-readable message, and optional field-level details.

{
  "success": false,
  "error": {
    "code": "VALIDATION_ERROR",
    "message": "Request validation failed",
    "details": [
      {
        "field": "campaign_id",
        "issue": "Field is required but was not provided",
        "expected": "The campaign identifier",
        "examples": ["carleads_main"]
      },
      {
        "field": "recipients",
        "issue": "At least one recipient is required",
        "expected": "Array with at least 1 recipient object"
      }
    ]
  }
}

Common Error Codes

HTTP	Code	Meaning
400	VALIDATION_ERROR	Missing or invalid fields
400	JSON_SYNTAX_ERROR	Malformed JSON body
401	AUTH_MISSING_TOKEN	No Authorization header
401	AUTH_INVALID_TOKEN	Token is malformed or tampered
401	AUTH_TOKEN_EXPIRED	Token expired — re-authenticate
401	AUTH_INVALID_CREDENTIALS	Wrong username or password
404	WA_NUMBER_NOT_FOUND	campaign_id + wa_number_id doesn't match a credential
400	WA_NUMBER_INACTIVE	WA number is disabled
202	(quarantined)	Circuit breaker open — messages quarantined

Field-Level Validation Details

Validation errors include a details array. Each entry has field (JSON path), issue (human-readable explanation), and optionally expected / examples. Interactive message limits return paths like content.buttons[0].title or content.sections[0].options[1].description.

{
  "success": false,
  "error": {
    "code": "VALIDATION_ERROR",
    "message": "Request validation failed",
    "details": [
      {
        "field": "content.buttons[0].title",
        "issue": "Button title must be 20 characters or fewer (got 28)"
      }
    ]
  }
}

Rate Limiting

Three layers of rate limiting protect your WhatsApp numbers and ensure compliance with Meta's policies:

1. Company Tier Limit (Daily)

Limits unique conversations per company per day.

Tier	Daily Limit
Initial	250 conversations
Tier 1	1,000 conversations
Tier 2	10,000 conversations
Tier 3	100,000 conversations
Tier 4	Unlimited

Exceeded messages are queued for the next day. A message_queued_tier_limit callback is sent.

2. WABA Hourly Throttle

Maximum 4,900 messages per hour per WhatsApp number (Meta allows 5,000 — we reserve 100 for buffer). Exceeded messages are queued and sent when capacity frees up. Status: "queued".

3. Circuit Breaker (Number Protection)

If a WhatsApp number shows high error rates (spam errors), the circuit breaker opens and all messages are quarantined to prevent Meta from banning the number. Recovery is automatic with escalating cooldowns: 4h → 14h → 28h → 32h.

Quarantined messages return HTTP 202 with status "quarantined".

4. Inter-Recipient Delay

A 100ms delayis applied between recipients in a batch to avoid bursting Meta's API. A batch of 10 recipients takes approximately 1 second.

All Endpoints

Method	Endpoint	Auth	Description
GET	/health	No	Service health check
POST	/auth/login	No	Get JWT token
POST	/api/v1/send/text	Bearer	Send text message
POST	/api/v1/send/image	Bearer	Send image message
POST	/api/v1/send/video	Bearer	Send video message
POST	/api/v1/send/document	Bearer	Send document message
POST	/api/v1/send/audio	Bearer	Send audio/voice message
POST	/api/v1/send/location	Bearer	Send location pin
POST	/api/v1/send/interactive	Bearer	Send buttons, list, or carousel
POST	/api/v1/send/template	Bearer	Send template message
POST	/api/v1/send/reaction	Bearer	React to a message with emoji
POST	/api/v1/messages/read	Bearer	Mark message as read
GET	/api/v1/templates	Bearer	List Meta WABA templates
POST	/api/v1/templates	Bearer	Create template on Meta
POST	/api/v1/templates/sync	Bearer	Sync templates from Meta
PUT	/api/v1/templates/{template_id}	Bearer	Edit Meta WABA template
DELETE	/api/v1/templates/{name}	Bearer	Delete template from Meta
POST	/api/v1/media/upload	Bearer	Upload media to Meta
GET	/api/v1/profile	Bearer	Get business profile
PUT	/api/v1/profile	Bearer	Update business profile
GET	/api/v1/companies	Bearer	List your companies
GET	/api/v1/campaigns	Bearer	List your campaigns
GET	/api/v1/contacts/lists	Bearer	List contact lists for a campaign
POST	/api/v1/contacts/lists	Bearer	Create contact list
GET	/api/v1/contacts/lists/{id}	Bearer	Get contact list
PUT	/api/v1/contacts/lists/{id}	Bearer	Update contact list
DELETE	/api/v1/contacts/lists/{id}	Bearer	Delete contact list
GET	/api/v1/contacts/lists/{id}/contacts	Bearer	List contacts in a list
POST	/api/v1/contacts/lists/{id}/contacts	Bearer	Add contacts (batch)
POST	/api/v1/contacts/lists/{id}/contacts/import	Bearer	Import contacts from CSV
GET	/api/v1/contacts/lists/{id}/contacts/export	Bearer	Export contacts to CSV
PUT	/api/v1/contacts/lists/{id}/contacts/{contact_id}	Bearer	Update contact
DELETE	/api/v1/contacts/lists/{id}/contacts/{contact_id}	Bearer	Delete contact
GET	/api/v1/saved-messages	Bearer	List saved message templates
POST	/api/v1/saved-messages	Bearer	Create saved message template
GET	/api/v1/saved-messages/{id}	Bearer	Get saved message template
PUT	/api/v1/saved-messages/{id}	Bearer	Update saved message template
DELETE	/api/v1/saved-messages/{id}	Bearer	Delete saved message template
GET	/api/v1/scheduled-messages	Bearer	List scheduled messages
POST	/api/v1/scheduled-messages	Bearer	Schedule message for later
GET	/api/v1/scheduled-messages/{id}	Bearer	Get scheduled message
PUT	/api/v1/scheduled-messages/{id}	Bearer	Update scheduled message
DELETE	/api/v1/scheduled-messages/{id}	Bearer	Cancel scheduled message
POST	/api/v1/scheduled-messages/process	Bearer	Process due scheduled messages
GET	/api/v1/analytics/summary	Bearer	Campaign analytics summary
GET	/api/v1/analytics/batches	Bearer	List message batches
POST	/api/v1/analytics/batches	Bearer	Create message batch
GET	/api/v1/analytics/batches/{id}	Bearer	Get message batch
PUT	/api/v1/analytics/batches/{id}/counts	Bearer	Update batch delivery counts
GET	/api/v1/tags	Bearer	List contact tags
POST	/api/v1/tags	Bearer	Create contact tag
PUT	/api/v1/tags/{id}	Bearer	Update contact tag
DELETE	/api/v1/tags/{id}	Bearer	Delete contact tag
GET	/api/v1/tags/{id}/contacts	Bearer	List contacts by tag
GET	/api/v1/contacts/{contact_id}/tags	Bearer	Get tags for a contact
POST	/api/v1/contacts/{contact_id}/tags	Bearer	Assign tags to contact
DELETE	/api/v1/contacts/{contact_id}/tags/{tag_id}	Bearer	Remove tag from contact
POST	/api/v1/contacts/duplicates/check	Bearer	Check for duplicate contacts
GET	/api/v1/contacts/duplicates	Bearer	Find all duplicate contacts
GET	/api/v1/client/messages	Bearer	Poll outbound message delivery log
GET	/api/v1/client/incoming	Bearer	Poll incoming messages / replies
GET	/api/v1/admin/shared-templates	Bearer	List platform shared templates
POST	/api/v1/admin/shared-templates	Bearer	Create shared template
GET	/api/v1/admin/shared-templates/{id}	Bearer	Get shared template
PUT	/api/v1/admin/shared-templates/{id}	Bearer	Update shared template
DELETE	/api/v1/admin/shared-templates/{id}	Bearer	Delete shared template
GET	/webhook/meta	Token*	Meta webhook verification
POST	/webhook/meta	No**	Meta webhook events

* Meta verification uses hub.verify_token query parameter (configured server-side)
** Meta signs webhook payloads; verification is handled internally

Ready to integrate?

Get your API credentials and start sending WhatsApp messages in minutes. Our team will set up your company, campaign, and WA credentials.

Request API Access View Pricing

APIDocumentation

Contents

Base URL

Authentication

Get Authentication Token

Request

Response (200 OK)

Using the Token

Common Request Fields

Recipient Object

Send Text Message

Single Recipient

Response (200 OK)

Multiple Recipients (Batch)

Response (200 OK)

Send Image

Send an Image Message

Response (200 OK)

Send Video

Send a Video Message

Response (200 OK)

Send Document

Send a Document

Response (200 OK)

Send Audio

Send an Audio/Voice Message

Response (200 OK)

Send Location

Send a Location Pin

Response (200 OK)

Send Interactive: Buttons

Reply Buttons (max 3)

Response (200 OK)

Send Interactive: List

List with Sections

Response (200 OK)

Interactive Message Limits

Validation error example

Send Template Message

Template with Variables

Response (200 OK)

Contact List Management

List Contact Lists

Response (200 OK)

Create Contact List

Response (201 Created)

Get Contact List

Response (200 OK)

Update Contact List

Response (200 OK)

Delete Contact List

Response (200 OK)

List Contacts in a List

Response (200 OK)

Add Contacts (Batch)

Response (200 OK)

Import Contacts from CSV

Response (200 OK)

Export Contacts to CSV

Response (200 OK)

Update Contact

Response (200 OK)

Delete Contact

Response (200 OK)

Saved Message Templates

List Saved Messages

Response (200 OK)

Create Saved Message

Response (201 Created)

Get Saved Message

Response (200 OK)

Update Saved Message

Response (200 OK)

Delete Saved Message

Response (200 OK)

content_json Structure by Type

Message Scheduling

List Scheduled Messages

Response (200 OK)

Schedule a Message

API
Documentation
